CorePlay Solo
Media Player

Heavy-duty 4K media player for live-operated applications

Button Text

Request a demo

Zenith 100

ZEN100

The Zenith 100 is a high-performance multi-screen & multi-layer 4K60 presentation switcher and videowall processor based on the powerful Alta 4K platform. Featuring heavy-duty design, 13 inputs and 4 outputs with versatile 4K connectivity, state-of-the-art real-time processing, advanced video effects and user-friendly HTML5-based user interface, the Zenith 100 is a perfect fit for medium to large-scale live events and fixed installations requiring the highest reliability and performance.

Tech Spec

SFP+

12G

SDI

HDMI

2.0

HDR

Management

Inputs

Outputs

4k60

4:4:4 10 bit

Multiviewer

Streaming

Up to 6

Layers

1.2

ZEN100

Extremely
USer-Friendly

The CorePlay RCS software is an intuitive, elegant, and powerful user interface to configure and control the Analog Way CorePlay products. CorePlay Solo offers IP (Ethernet) based API which enable easy integration with any third-party control systems. CorePlay Solo is also compatible with various remote control software such as Stream Deck Companion. CorePlay Solo natively supports Stream Deck directly connected to the unit.

Button Text

Key Features

Perfect companion to Presentation Switchers

4K@60Hz 10-bit output and high playback performance make CorePlay Solo a powerful and versatile video playback solution for live events. System performance is predictable and well documented, so it will be easy for operator to communicate on the media specifications.

Playback quality will be optimal, with direct support for most common media formats and preview operations will not disrupt the program outputs.

Button Text

Key Features

Built for live events and rental staging applications

It’s the small things in CorePlay that make life easy in live events and rental applications. With a full hardware solution, you won’t need to worry about surprise operating system updates breaking the show – Analog Way will handle all the details, CorePlay will just work.

Turnaround time in the shop will be minimized by having fast, easy and safe procedure to reset the units to factory defaults and to optionally wipe the media storage. This prevents accidents with medias leaking from one customer to another customer.

Button Text

Key Features

Rock-solid reliability

CorePlay Solo is designed to offer a robust and reliable hardware platform that you can rely on for all of your video playback needs. It is specifically engineered to survive tough live event environments while ensuring long-term durability for fixed installations. Powered by a Linux engine, renowned for its exceptional reliability and stability, CorePlay Solo delivers optimal performance, even in the toughest conditions.

Button Text

overview

Elevate Your Connectivity and Performance

Thank you! Your submission has been received!

Oops! Something went wrong while submitting the form.

13 Inputs

6x HDMI 2.0 - up to 4K60 8-bit 4:4:4 or 4K60 12-bit 4:2:2
3x DisplayPort 1.2 - up to 4K60 10-bit 4:4:4 or 4K60 12-bit 4:2:2
2x 12G/6G/3G-SDI (level A & B) - up to 4K60 10-bit 4:2:2

2x HDMI 1.4 or 3G-SDI (user selectable input plug) - up to 2K60 10-bit 4:4:4 (HDMI) or 2K60 10-bit 4:2:2 (SDI)
Support custom input formats up to 4096 width / height

‍

Livestreaming

RTMP-based livestreaming of any input or output (including Multiviewer) 
Compatible with all major Web platform such as YouTube, Facebook or Twitch.tv 
Streaming to a private network to feed local clients like OBS software

Encoding at up to 1080p30 in H.264 for the video and AAC for the audio 
Predefined video quality sets or custom bitrate for dedicated application 
Management of the personal credentials for web services (URL and Private Key)

Other Features

Rugged 3RU chassis with cleanable air filter
Live monitoring of inputs on the color TFT LCD display
Innovative ‘Quick Preset’ feature
Dedicated BNC with loop for Genlock, Blackburst and tri-level sync

I/O connector status LEDs for easy troubleshooting
USB host type A: firmware update, configuration import/export...
Fully functional simulator for offline configuration & practice
Gigabit Ethernet via Neutrik RJ45

4 Active Ouputs

2 outputs with mirrored HDMI 2.0 and 12G-SDI connectors (level A & B)
2 outputs with mirrored HDMI 2.0, 12G-SDI (level A & B) and SFP+ connectors (compatible with Analog Way's fiber optic or ST2110 SFP modules)

Up to 4K60 8-bit 4:4:4 or 4K60 12-bit 4:2:2 (HDMI)
Up to 4K60 10-bit 4:2:2 (SDI / SFP+)
Support custom output formats up to 4096 width / height

Up to 6 Layers

Support of mixing (seamless transitions) and split (cut transitions) layers
Up to 6 split layers (or 3 mixing layers)

Live or still image background available on all PGM outputs
Additional still image foreground layer available on all screens

‍

Advanced Video Effects

Layer border effects and colors with separate shadow
Multiple transition effects
Luma and Chroma Keying

Cut and Fill at input level
Layer effects: H/V Flip, Transparency…
Color effects: B&W, Negative, Sepia and Solarize

‍

Flexible Control Options

Large color TFT LCD display (480x272 pixels) with full-featured menu
Web RCS: on-board intuitive HTML5-based user interface
Built-in SMNPv2-MIB
Shot Box2 / Control Box3: Cost effective control solutions
RC400T: Ergonomic event controller

Compatible with SKARHOOJ Air fly Pro controller
Compatible with Companion and Universe control solutions
Simple REST API (HTTP) and advanced JSON TCP protocol
Creston drivers
AW VideoCompositor (Premium Creston GUI)

Advanced Audio Processing

De-embed/embed audio channels on all inputs/outputs (PCM):
- 8 channels per HDMI 2.0, 12G-SDI or DisplayPort 1.2 input
- 4 channels per 3G-SDI input and 2 channels per HDMI 1.4 input 8 channels per active output
- 8 channels per active output

Level control, Mute, Balance, Delay, 1kHz Sinus Pattern features
1 VU meter display of a selected input on the multiviewer

Fixed or dynamic routing (breakaway or top layer)
Optional Analog and Dante™ audio networking card:
- 2 analog stereo mini jack line in and line out 1/8’’ (3.5 mm)
- 32x32 Dante™ audio channels @48kHz
- Dual redundancy Ethernet ports - AES67 support

8 Concurrent 4K Still Images

Up to 4x 4K concurrent still images available per screen for the background layer
Alpha-channel support
Still image library with 50 memories

Multi-file download/upload via Web RCS
Capture from live inputs and outputs

‍

Dedicated Multiviewer Output

1 output with mirrored HDMI 1.4 and 3G-SDI connectors
Up to 2560x1600@60 8-bit 4:2:2
27 resizable widgets - customizable layouts (20 memories)

Monitor the Program, Preview and auxiliary screens and all the inputs
Built-in clocks, countdown and timers

‍

Ultra-low Latency 4K60 Processing

Based on Analog Way exclusive 5th generation scaling engine
Native 4K60 10-bit 4:4:4 video processing
Ultra-low latency (as low as 16msec @60Hz)
BT.709 and BT.2020 color spaces support
Advanced EDID management

Area of Interest and advanced output/screen test patterns
HDR processing including real-time SDR/HDR conversion
Advanced color correction with custom external 3D LUTs
High Frame Rate up to 144Hz
Compatible with HDCP 1.4 and HDCP 2.2

Flexible Screen and Layer Management

Outputs configurable as up to 3x 4K60 PGM outputs (single screens or edge-blended widescreens)
Unused outputs configurable as scaled auxiliary 1080p60 outputs (2 max)

Flexible layer resource management 
200 user definable screen memories and 50 master memories

‍

want to dive deeper

Download Datasheet

No items found.

Start to configure now

main accessories

Key Features

4K60 multi-output, multi-layer live presentation switcher
13 inputs (11x 4K60 + 2x 2K60 inputs) with versatile connectivity (HDMI, DisplayPort and SDI)
4 outputs (2 with mirrored HDMI 2.0, 12G-SDI and SFP+ plugs and 2 with mirrored HDMI 2.0 and 12G-SDI plugs)
Outputs configurable as up to 3x 4K60 PGM outputs (single screens or edge-blended widescreens)
Unused outputs configurable as scaled auxiliary outputs at 1080p60 (2 auxiliary outputs max.)
Live or still image background available on all PGM outputs
Up to 6x 4K split layers (or 3x 4K mixing layers)
Additional still image foreground layer available on all screens
Dedicated multiviewer with resizable widgets
Class-leading 4K60 10-bit 4:4:4 video processing with 1 frame latency
HDR processing including real-time SDR/HDR conversion
RTMP-based livestreaming (up to 1080p30) of any input or output
Advanced audio processing and dynamic routing
Optional analog and Dante audio networking card (32x32 channels)
Dedicated BNC with loop for Genlock, Blackburst and tri-level sync
Intuitive HTML5-based user interface with live source thumbnails
3RU rugged chassis

‍
